Intel 82576-F2 Fiber 1000M SFP Network Card 82576EB
The Intel 82576-F2 Fiber 1000M SFP Network Card 82576EB delivers reliable and high-speed Fiber Ethernet connectivity for servers and data centers. With dual 1GbE SFP ports, advanced offload capabilities, and support for VLAN tagging and link aggregation, it ensures efficient and stable network performance. Ideal for Windows, Linux, and VMware environments, this PCIe network card is a perfect choice for robust server networking solutions in Bangladesh.
Specification Table
| Feature | Details |
|---|---|
| Model | Intel 82576 |
| Interface | PCI Express 2.0 x8 |
| Network Type | Fiber Ethernet |
| Ports | 2 × 1GbE (SFP) |
| Supported Media | Fiber optic (SX/LX), Copper (optional with module) |
| Data Rate | 10/100/1000 Mbps |
| MAC Address | 2 |
| Jumbo Frame Support | Up to 9,000 bytes |
| Wake-on-LAN (WoL) | Yes |
| VLAN Support | 802.1Q VLAN tagging |
| Link Aggregation | Supported (802.3ad) |
| Offload Capabilities | TCP/UDP checksum, Large Send Offload (LSO) |
| Operating Systems | Windows, Linux, VMware |
| Dimensions | Standard PCIe low-profile card |
| Power Consumption | ~6–10W |
Description
The Intel 82576 Fiber Network Card is a high-performance dual-port Gigabit Ethernet adapter designed for both enterprise and data center environments. Built with Intel’s reliable networking technology, this card offers exceptional throughput, low latency, and energy-efficient operation. Featuring two SFP fiber ports, it supports a wide range of fiber transceivers, including SX and LX modules, enabling connectivity over long distances without signal degradation.
This card is fully compatible with PCI Express 2.0 x8 slots and includes advanced features such as TCP/UDP checksum offload, Large Send Offload (LSO), and VLAN tagging, which optimize network performance and reduce CPU utilization. Its support for link aggregation (802.3ad) allows multiple network interfaces to be combined, increasing redundancy and bandwidth for mission-critical applications.
Additionally, the Intel 82576 provides Wake-on-LAN functionality for remote power management and efficient deployment in virtualized environments, including VMware. With jumbo frame support up to 9,000 bytes, it is ideal for high-volume data transfers, backup solutions, and server clustering. Its robust driver support for Windows and Linux ensures seamless integration into existing networks. Compact and power-efficient, this network card is a reliable choice for businesses seeking stable, high-speed fiber connectivity.
Key Features
- Dual-port Gigabit Fiber Ethernet adapter
- Supports PCI Express 2.0 x8 interface for high-speed connectivity
- Advanced features: VLAN, QoS, and TCP/IP offloading
- Compatible with Intel® Virtualization Technology for connectivity (VT-c)
- Low power consumption with energy-efficient Ethernet (EEE)
Where it Can Be Used
- Enterprise servers requiring high-speed fiber connectivity
- Data centers with fiber backbone infrastructure
- High-performance computing environments
- Network-intensive applications like virtualization, storage networks, and database servers
Installation Steps
- Power off the server or PC and unplug all cables.
- Insert the card into an available PCIe x8 slot.
- Secure the card with screws to the chassis.
- Connect fiber optic cables to the appropriate ports.
- Power on the system and install Intel’s driver software.
- Verify the network connectivity through the OS or network management tool.
