About HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit(878783-B21)
HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit is a crucial component for boosting your server’s performance. This cutting-edge solution empowers you to harness the speed and efficiency of M.2 SSDs in a half-height, half-length form factor. Experience faster data access, reduced boot times, and enhanced overall system responsiveness with this essential upgrade.
Product Specification
| Feature | Specification |
|---|---|
| Interface | SATA 6Gb/s |
| Form Factor | Half-Height Half-Length (HHHL) |
| M.2 SSD Compatibility | 2280 size |
| Plug Type | Non-hot pluggable |
| Dimensions | 7.5 x 9.5 x 2.25 in (19.05 x 24.13 x 5.71 cm) |
| Weight | 0.58 lb (0.26 kg) |
Description:
The HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit (878783-B21) allows you to install a SATA M.2 solid-state drive (SSD) into a compatible HPE ProLiant rack, tower, blade, or Synergy server. This kit provides a half-height, half-length (HHHL) adapter card that connects to the server’s motherboard via a standard PCIe slot. The adapter card then accepts a single 2280 form factor M.2 SATA SSD. This enables you to add additional storage to your server for improved performance and boot times.
M.2 SSDs are small, high-performance storage devices offering significant advantages over traditional hard disk drives (HDDs). They boast faster data transfer speeds, improved responsiveness, lower power consumption, and better durability due to their lack of moving parts. This kit essentially expands your server’s storage capabilities by enabling the use of these modern SSDs.
The “Universal” in the name indicates compatibility with a wide range of HPE servers. However, it’s crucial to verify compatibility with your specific server model before purchasing the kit. This information can typically be found in your server’s user manual or on the HPE website.
Here’s a breakdown of the key terms in the kit’s name:
SATA 6G: This refers to the Serial ATA (SATA) interface revision 3 (3.0) which supports data transfer speeds of up to 6 gigabits per second (Gbps). While not the latest interface standard, it’s still sufficient for many applications and offers a balance between performance and cost.
AIC: Stands for “Add-in Card.” This signifies that the kit is an expansion card that you install into a PCI Express (PCIe) slot on your server’s motherboard. PCIe is a high-speed interconnect providing the bandwidth necessary for optimal SSD performance.
HHHL: This stands for “Half-Height Half-Length.” It’s a standard size format for expansion cards, ensuring it fits within the physical space limitations of your server chassis.
M.2: This refers to the physical form factor of the M.2 SSDs that the kit supports. M.2 SSDs come in various sizes, and the specific size compatibility information might be available in the kit’s documentation.
Installing the kit typically involves opening your server chassis, locating a compatible PCIe slot, and securing the card in place. Then, you can mount your compatible M.2 SSD onto the kit’s designated socket and connect it using the provided cables.
The HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit (878783-B21) is a valuable upgrade for HPE server owners seeking to leverage the benefits of M.2 SSDs. It boosts storage performance, improves system responsiveness, and potentially reduces power consumption. Remember to ensure compatibility with your server model before purchasing the kit.
How much does the HPE Universal SATA 6G AIC HHHL M.2 SSD Enablement Kit(878783-B21) cost in Bangladesh?
The price of the HPE SATA 6G AIC HHHL M.2 SSD Enablement Kit(878783-B21) can vary depending on market conditions and purchase volume. Since prices can fluctuate, they might not be listed online. However, contacting Datacom Technologies Bangladesh can get you a competitive quote based on your needs. Visit our website Server SSD Bangladesh or reach out through WhatsApp: +8801748173213 or email: sales@datacomtechbd.com or datacomtechnologiesbd@gmail.com.
