Corelink CW-3302H 100KM Mini OTDR
The Corelink CW-3302H 100KM Mini OTDR is a compact and powerful handheld optical time domain reflectometer designed for precise fiber testing and troubleshooting. With dual wavelengths of 1310nm and 1550nm, it ensures accurate measurement and performance analysis over long distances up to 100KM. Ideal for fiber network maintenance, this OTDR offers reliability and efficiency for professionals in Bangladesh.
Specification Table
| Specification | Details |
|---|---|
| Model | Corelink CW-3302H |
| Type | Handheld Mini Optical Time Domain Reflectometer (OTDR) |
| Testing Distance Range | Up to 100KM |
| Wavelength | 1310nm / 1550nm (Dual Wavelength) |
| Dynamic Range | 32dB / 30dB |
| Pulse Width | 3ns to 10µs |
| Event Dead Zone | ≤ 2m |
| Attenuation Dead Zone | ≤ 8m |
| Measurement Units | km, ft, mi |
| Display | 3.5-inch Color LCD Touchscreen |
| Storage Capacity | Up to 1000 test results |
| Interface | USB Port for Data Transfer |
| Power Supply | Rechargeable Lithium Battery |
| Battery Life | Up to 8 hours continuous operation |
| Operating Temperature | -10°C to +50°C |
| Weight | Approx. 0.9 kg |
| Dimensions | 190 x 130 x 70 mm |
Description:
The Corelink CW-3302H 100KM Mini OTDR is a compact and highly efficient optical time domain reflectometer designed for fiber optic network installation, maintenance, and troubleshooting. This handheld device combines portability with powerful performance, offering testing capabilities up to 100 kilometers with excellent precision. Equipped with dual wavelengths of 1310nm and 1550nm, it ensures accurate measurement of fiber length, loss, and fault locations in both single-mode and multi-mode optical fibers.
The CW-3302H features a 3.5-inch color LCD touchscreen that provides clear graphical trace analysis, making it easy for technicians to interpret data in real time. Its user-friendly interface and fast response time simplify complex testing tasks. The built-in lithium battery supports up to 8 hours of continuous operation, making it ideal for fieldwork. Data storage and transfer are made convenient through its USB interface, allowing users to save and share results efficiently.
With a robust design and reliable performance, the Corelink CW-3302H is suitable for telecom networks, CATV, LAN, and data center applications. Whether you are verifying new fiber installations or diagnosing faults in existing systems, this mini OTDR delivers professional-grade results in a portable, durable form factor.
Key Features:
- Measurement Range: Up to 100KM for long-distance fiber testing
- Wavelengths: 1310nm / 1550nm dual wavelength operation
- High Dynamic Range: 32dB/30dB for accurate reflection detection
- Display: 4.3-inch color touchscreen for easy navigation
- Storage: Built-in memory for saving test data and results
- Battery: Rechargeable lithium battery with up to 10 hours of operation
- Interface: USB port for data export and PC connectivity
- Auto Test Function: Quick one-touch testing and result analysis
- Lightweight & Portable: Compact design ideal for field use
- Built-in Visual Fault Locator (VFL): Helps identify breaks or faults visually
Where It Can Be Used?
The Corelink CW-3302H 100KM Mini OTDR is perfect for fiber optic network maintenance, installation, and troubleshooting. It is widely used by telecom service providers, data centers, and network engineers. It can be applied to single-mode fiber networks for long-distance backbone testing, FTTH (Fiber to the Home) installation, and LAN/WAN fiber verification.
Installation Step:
Charge the OTDR fully before first use.
- Connect the fiber patch cord to the OTDR’s optical port.
- Select the testing wavelength (1310nm or 1550nm).
- Choose the measurement range (up to 100KM as needed).
- Press “Auto Test” or “Start Test” to begin scanning.
- View the test trace on the screen and save the results.
- Disconnect the fiber cable carefully and clean the port after use.
Buy Corelink CW-3302H 100KM Mini OTDR at the Best Price from Server SSD BD.
In Bangladesh, you can get Corelink CW-3302H 100KM Mini OTDR From Server SSD BD. We have a large collection of latest Corelink Mini ODTR to purchase for your Data Center. Order Online Or Visit our Office to get yours at lowest price. The Corelink CW-3302H Mini OTDR comes with 1 Year warranty.
Get in Touch with Server SSD Bangladesh
- 📞 Call/WhatsApp: 01748173213
- ✉ Email: sales@datacomtechbd.com | datacomtechnologiesbd@gmail.com
What is the price of Corelink CW-3302H 100KM Mini OTDR in Bangladesh?
The estimated price of Corelink CW-3302H 100KM Mini OTDR in Bangladesh is 0৳. You can buy the Corelink CW-3302H Mini OTDR at best price from our website or visit our Office.
For the most accurate pricing, stock availability, and warranty details, we recommend contacting us before placing your order.
