Broadcom 9361-16i RAID Controller Card
The Broadcom MegaRAID SAS 9361-16i RAID Controller Card is a high-performance solution designed to support up to 240 SATA and SAS devices, making it ideal for enterprise storage environments. Equipped with a powerful dual-core ROC processor and 2GB DDR3 cache, it delivers reliable data protection with multiple RAID levels including 0, 1, 5, 6, 10, 50, and 60. Perfect for enhancing server performance, this RAID controller ensures fast data transfer rates of up to 12Gb/s per port with advanced management tools for easy configuration.
Specification Table
| Feature | Specification |
|---|---|
| Model | Broadcom MegaRAID SAS 9361-16i |
| Form Factor | Low-profile MD2 |
| Interface | PCI Express 3.0 x8 |
| Processor | SAS3316 Dual-core RAID-on-Chip (ROC) |
| Cache Memory | 2GB DDR3 SDRAM (1866 MHz) |
| Internal Ports | 16 (via 4 x SFF-8643 mini-SAS HD connectors) |
| Data Transfer Rate | Up to 12 Gb/s per port |
| Supported Devices | Up to 240 SATA and/or SAS devices |
| RAID Levels | 0, 1, 5, 6, 10, 50, 60 |
| Management Software | MegaRAID Storage Manager, StorCLI, CTRL-R (BIOS), HII (UEFI) |
| Cache Protection | Optional CacheVault Module (CVPM02) |
| Operating Temperature | Up to 55°C (without CacheVault), 60°C (with CacheVault) |
| Dimensions | 6.127″ x 2.712″ (155.65 mm x 68.90 mm) |
| MTBF | > 2,500,000 hours |
| Voltage | +12V, +3.3V |
📝 Product Description:
The Broadcom MegaRAID SAS 9361-16i is a high-performance RAID controller designed for enterprise storage solutions. Featuring a low-profile MD2 form factor, it integrates seamlessly into various server configurations.
At its core, the SAS3316 dual-core RAID-on-Chip (ROC) processor delivers robust data processing capabilities, ensuring efficient management of connected storage devices. The controller boasts 16 internal ports, accessible via four SFF-8643 mini-SAS HD connectors, supporting data transfer rates of up to 12 Gb/s per port. This design facilitates direct connections to a high number of drives, with support for up to 240 SATA and/or SAS devices when utilizing SAS expanders.
Equipped with 2GB of DDR3 SDRAM operating at 1866 MHz, the 9361-16i ensures rapid data caching, enhancing overall system performance. It supports a wide range of RAID levels—including 0, 1, 5, 6, 10, 50, and 60—providing flexibility in data redundancy and performance optimization.
For data protection, the optional CacheVault™ Power Module (CVPM02) offers backup power to preserve cached data during unexpected power losses. Management is streamlined through tools like MegaRAID Storage Manager, StorCLI, and BIOS/UEFI interfaces, allowing administrators to configure and monitor storage setups efficiently.
Key Features
- Supports 16 internal SATA/SAS ports (6Gb/s each).
- Compatible with RAID levels 0, 1, 5, 6, 10, 50, 60.
- PCIe 3.0 x8 interface for high-speed data transfer.
- Supports Up to 512 SATA/SAS devices with expanders.
- Includes 1GB Flash-Backed Cache (FBC) for enhanced performance and data protection.
- Supports JBOD mode for direct drive access.
- Broadcom MegaRAID Software Suite for monitoring, configuration, and management.
- Low-profile form factor suitable for 2U/4U servers.
Where it Can Be Used?
- Ideal for enterprise servers requiring high-performance storage solutions.
- Suitable for database servers, virtualization environments, and media rendering servers.
- Can be used in data centers for RAID or JBOD configurations.
- Compatible with servers from Dell, HP, Supermicro, and custom-built systems that support PCIe RAID cards.
Installation Steps
- Power off the server and unplug all cables.
- Insert the card into an available PCIe x8 or higher slot.
- Connect SAS/SATA cables from drives to the controller card.
- Secure the card with screws and close the server chassis.
- Power on the server and enter the RAID BIOS/UEFI utility.
- Configure RAID arrays or JBOD mode as required.
- Install the operating system drivers for Broadcom MegaRAID.
- Verify the configuration in the OS using management software.
